Scott Sub Tour 40 Wave
The Sub Tour 40 Wave E-Bike is our value-packed urban ride that combines affordability, convenience, and smooth power to get you out of the car and enjoying your city by bike.
Please note that bike specifications are subject to change without prior notice.
Frame
Alloy S-XL=29", 6061 Alloy custom butted tubing
Top extraction battery
UDH Interface, 135mm with 46mm Beltline
Travel
100mm
Fork
SR Suntour NVX 32 5TA NLO Coil, Tapered, 5x100 TA, Lock Out, 100mm Travel
Drive Unit
Bosch Performance Line (BDU346Y)
EU: 25kmh
Battery
PowerTube 540Wh
Display
Bosch Purion 200
Charger
2A Charger
Shifters
Shimano Nexus Inter 5e
Crankset
Miranda Virage 170mm
Chainring
Miranda 38T
Chain
KMC Z1
Cassette
Shimano CSC700027 27T
Brakes
Shimano BR-MT200 Disc
Rotor
Front: SM-RT30 CL 180mm, Rear: SM-RT30 CL 160mm
Handlebar
Syncros UC3.0 680mm, Rise 12mm, Backsweep 15°
H'stem
Syncros UC 3.0 adjustable with front Light mount and Intuvia 100 mount
Seatpost
Syncros 3.0, 31.6mm, 350mm
Seat
Syncros Capilano
Headset
Acros, 1.5"- 1.5"
semi integ. OD 50/61mm, ID 44/55mm
Front Hub
Shimano HBQC400B58LL, 5x100mm
Rear Hub
Shimano Nexus Inter 5e
Spokes
Black Spokes
Rims
Syncros X18 Disc
Front Tire
Schwalbe Big Apple Performance, 55-622
Rear Tire
Schwalbe Big Apple Performance, 55-622
Lights
Front Lezyne Hecto E65
Rear Super Bright Lezyne Light
Rack
Racktime carrier SnapIt 2.0 25KG
Pedals
Marwi SP-828
Approx weight in KG
29.7
Approx weight in LBS
65.48
Max. System Weight
160kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
