MEGAMO REASON AL 05
Megamo Reason AL 05 Alloy Avinox E.Mountain Bike - BlackSeason:2026 Brand:Megamo Code:MG38005BLK The Reason AL 05 Introduces the performance that the DJi Avinox system can offer in a proper sorted component package based around Megamo's superbe alloy Reason trail chassis with 160mm travel at both ends.
Designed to offer the perfect balance between reduced weight and high-level performance. Choose between the strength of aluminum or the reactive lightness of carbon. Its adjustable geometry and optimized kinematics ensure agility, control, and efficiency across all types of terrain. Thanks to DJI's Avinox system, you’ll enjoy powerful and smooth assistance, ideal for both demanding climbs and technical descents. A light, precise, and rider-adaptable e-bike.
DJI Avinox M1 Motor -120Nm 1000W (Boost mode) / 105Nm 1000W
Integrated 800 Wh LI-ION battery
Hi-Res Oled touch screen
GPS and Sim enabled security tracking
Reason Alloy frame, Boost, 160 mm wheel travel
Fox 36 Performance fork with 160 mm travel
Fox Float X Performance shock
Sram 90 Eagle drivetrain, 12-speed
Shimano XT 4-piston hydraulic disc brakes
Megamo SL 30 Alloy Wheel Set
The REASON is redefining the e-bike category with a high-performance frame that´s both lightweight and engineered with unbeatable kinematics. It absorbs vibrations without sacrificing responsiveness and delivers agility, control and precision at all times. Its sleek, integrated design looks just like a muscular bike - no one would guess it's electric, not even up close.
With a Flip Chip system that allows you to adjust the frame’s geometry quick and easy. Modify the head tube and rear triangle angles to suit your riding style or terrain type. One frame, four possible configurations. Maximum versatility for riders who want it all.
Responsiveness
Immediate and precise response to every movement.
Design Integration
Clean, modern design with advanced integration and standout aesthetics.
Lightness
The Reason is lighter without compromising performance, improving agility and efficiency on demanding terrain.
Technical information
×
Frameset
Frame Reason AL Frame, Alloy shock extension, Full Integratted Battery, 12 x 148 Boost, Megamo ASP, Wheel travel: 160 mm
Fork Fox 38 Float Performance E-Bike Optimized, 160mm Travel, Grip
Shock Fox Float X Performance, 210x55mm, 2 Position
Headset Acros AZA-288R2 ZS56 blocklock 135º
Electronic components
Motor Avinox M2S -150Nm 1300W (Boost mode) / 130Nm 1300W
Battery Avinox 800 Wh, 35,9V, IP56
Display Avinox DP100, 2-inch full-color OLED touchscreen, 800 nits, 326 ppi
Charger Avinox 4A Charger
Drivetrain
Rear Derailleur Sram 90 EAGLE T-TYPE, 12-Speed
Shifters Sram 90 EAGLE T-TYPE
Crankset Sram EAGLE T-TYPE Avinox Chainring 36T 12-Speed, Crankset 160mm
Cassette Sram XS 1270 T-TYPE, 10-52T
Brakes
Brakes Shimano XT M8220, Hydraulic Disc 4-Piston, SM-RT86 203 mm
Wheels
Tires Front: Maxxis Assegai 29x2.5 DD 3C MaxxGrip / Rear: Maxxis Minion DHR II 29x2.4 DD 3C MaxxTerra
Wheels Megamo 29 SL 30 ASY, Aluminium Rim, 15x110/12x148 mm
Components
Handlebar Megamo Alloy Butted 35 x 800 mm, 12 mm Rise, 6º Back Sweep
Stem Satori Ursa, 35 x 35 mm
Seatpost Megamo Ø31.6 mm
Seat Fizik Terra Aidon X5, 145 mm
* Megamo reserves the right to change any component, if necessary by replacing it with an equivalent one, without prior notice.
