Specification

SPECIFICATION
FRAME
7005 hydroformed aluminium, 3D forging, 150 mm F.O.L.D. kinematic, 148x12 mm thru axle, internal cable routing, post mount 180 mm
FRAME MATERIAL
Aluminium
FORK
FOX 36 Float Performance 29, Grip 3-Position, 110x15 mm, 44 mm rake, 150 mm travel
TRAVEL FORK
150 mm
SHOCK
FOX Float DPS Performance, 3-position lever, 210/55 mm, hardware: 25,0 x 8mm, custom tune
SHIFTER
Shimano Deore XT M8100, 12-speed
REAR DERAILLEUR
Shimano Deore XT M8100, 12-speed
SPROCKET
Shimano Deore M6100, 12-speed
CHAIN
Shimano CN-LG50
CRANKSET
Shimano Deore XT FC-M8100, Hollowtech II
BOTTOM BRACKET
BSA
TRANSMISSION OF DRIVE
front: 32, rear: 11-51
HANDLEBAR
Aluminium 35 mm, riserbar 28mm, 780mm
STEM
FOCUS C.I.S. integrated, 50 mm, 0°, 35 mm, aluminium
HEADSET
ACROS ZS56/ZS56, FOCUS C.I.S. Integrated
SADDLE
FOCUS Trail SL
SEATPOST
Post Moderne dropper post PM-171, 31.6 mm
BRAKES
Shimano XT M8120, 4 piston
BRAKE LEVER
Shimano XT M8120, 4 piston
BRAKE
Disc
RIMS
RODI TRYP30, 30-622
REAR HUB
Novatec D462 Disc, 12x148 mm
FRONT HUB
Novatec D041, 15x110 mm
TIRES
Maxxis Minion DHF 2.5 WT 3C Grip EXO TR
REAR TIRE
Maxxis Minion DHR II 2.4 3C EXO+ TR
GEARS
12
BIKE WEIGHT INCL. BATTERY IN KG.
16,10 kg
SIZE
39,42,45,47
Subject to technical modification without notice. Errors and omissions excepted.
* Weight in size M, of standard specification and without pedals.
